02 GM 5.3 with Jim's Performance harness and tune.
Has truck intake, oil pan, and accessory drive.
Custom headers and 2.5" exhaust with a single Magnaflow muffler.
TH 400 transmission with stock converter....
reverse valve body so it will hold first gear at any rpm.
Clocked and Twin Sticked 205.
-Front is a Chevy LP 60 with Dodge external style hubs.
5:13 Gears and welded carrier. Have
35 spline Chrome Moly inners and outers.
2x3 3/16" wall box tubing truss.
6" stroke DE ram with 3/4 heims on tie rods.
BTF diff cover and 1350 yoke.
-Rear is a 14 Bolt with BTF diff cover and brake brackets with 3/4 ton rotors and calipers.
5:13 Gears and Detroit Locker.
Also has a 2x3 3/16" truss
Based off a YJ frame and has 1.75 DOM tubing.
All links are 1.5" 1/4 wall DOM with 3/4 chrome moly heims.
Radflo 14" 2.0 coil overs front an rear with remote reservoirs on the rear.
Tires are 43 tsp sx on 15x8 steel wheels trail ready beadlocks. Have about 95 %tread.
Corbea Baja SS seats and Simpson Harnesses.
Quick Car switch panel and gauges (water and oil).
Tilton dual 3/4 master cylinders with single Wilwood pedal.
Steering is a factory pump with PSC cooler.
Full 1/8" aluminum top.
Speedway 22x19 radiator.
Smittybilt XRC 8 winch with synthetic rope.
15 gallon fuel cell.
Willis grill and hood.
1/4" wall front driveshaft
Full custom wrap around snap in windows
17,500$ with heavy duty Turn and Burn trailer with drive over fenders Tulsa Oklahoma 918-938-3437 call or text for fastest response
Open to 4 seater trades, prefer full body TJ
